SPECIFICATIONS

Brand Name: U-Angel-1988

Choice: yes

For Vehicle Type: Airplanes

Four-wheel Drive Attributes: M100 GPS Module

High-concerned chemical: None

Is Batteries Included: No

Is Electric: No Battery

Is it battery/power supply: N

Is it charger/adapter: N

Material: Metal

Model Number: GPS Module

Origin: Mainland China

Quantity: 1 pcs

RC Parts & Accs: Gyros

Recommend Age: 14+y

Remote Control Peripherals/Devices: ESC

Size: 21x21x8.02mm

Technical parameters: value 2

Tool Supplies: Assembled class

Upgrade Parts/Accessories: HGLRC M100 PRO GPS

Use: Vehicles & Remote Control Toys

Wheelbase: Screws

Satellite system: GPS L1 C/A GLONASSL10F BeiDouB1I/B1C Galileo E1B/C QZSSL1 C/A/S SBAS L1C/A
Number of satellite concurrency: 3
Maximum navigation update rate: 10Hz
Maximum number of navigation satellites: 32
Positioning accuracy (ideal environment): 1.5m CEP
Start-up speed (ideal environment): 26 seconds for cold start and 1 S for hot start
Sensitivity: Tracking & Navigation: -167dBm Recapture: -160dBm Hot Start: -159dBm Cold Start: -148dBm
Hot start support: With backup battery, support hot start
Serial port baud rate: 4800-921600bps, default 115200bps
Output level: 3.3VTTL level
Output protocols: NMEA, UBX
FLASH: Onboard FLASH, which can be saved after configuration modification and will not be lost when the power is off
Height limit: ≤50000m
Speed limit: ≤500m/s
Acceleration limit: ≤4g
Working voltage: DC 3.6-5.5V, typical 5.0V
