Matek Systems PDB XT60 W/ BEC 5V & 12V 2oz Copper For RC Helicopter FPV Quadcopter Muliticopter Drone Power Distribution Board
Matek Systems PDB XT60 W/ BEC 5V & 12V 2oz Copper For RC Helicopter FPV Quadcopter Muliticopter Drone Power Distribution Board Original price was: $28.92.Current price is: $16.87.
Back to products
Radiolink R12DSM R12DS R9DS R8SM R8EF R8FM R8F R7FG R6DSM R6DS R6FG R6F R4FG R4F Rc Receiver 2.4G Signal for RC Transmitter AT9S
Radiolink R12DSM R12DS R9DS R8SM R8EF R8FM R8F R7FG R6DSM R6DS R6FG R6F R4FG R4F Rc Receiver 2.4G Signal for RC Transmitter AT9S Price range: $49.39 through $110.11
Sale
Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range - Image 1
Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range - Image 2
Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range - Image 3
Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range - Image 4
Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range - Image 5
Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range - Image 6
Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range - Image 7
Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range - Image 8
Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range - Image 9
Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range - Image 10
Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range
Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range - Image 2
Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range - Image 3
Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range - Image 4
Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range - Image 5
Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range - Image 6
Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range - Image 7
Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range - Image 8
Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range - Image 9
Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range - Image 10

Foxeer M10Q-180 M10Q-250 M10 Dual Protocol GPS Module Built-in QMC5883 Compass Ceramic Antenna for RC Airplane FPV Long Range

Price range: $117.88 through $119.35

Get A Quote

"*" indicates required fields

Add to wishlist
SKU: d6lc0rdl2ui000djldqg Category:
Description

SPECIFICATIONS


Brand Name: U-Angel-1988

Choice: yes

For Vehicle Type: Airplanes

Four-wheel Drive Attributes: m10q gps

High-concerned chemical: None

Is Batteries Included: No

Is Electric: No Battery

Is it battery/power supply: N

Is it charger/adapter: N

Material: Metal

Model Number: GPS Module

Origin: Mainland China

Quantity: 1 pcs

RC Parts & Accs: Gyros

Recommend Age: 14+y

Remote Control Peripherals/Devices: ESC

Size: 32mm x 34mm x 6mm

Technical parameters: value 2

Tool Supplies: Assembled class

Upgrade Parts/Accessories: foxeer GPS Module

Use: Vehicles & Remote Control Toys

Wheelbase: Screws


Chip

M10(10th Generation Chip)

Frequency

GPS L1GLONASS L1BDS B1GALILEO ESBAS L1QZSS L1

Input Voltage

5V

Antenna

Ceramic Antenna

Channel

72

Battery

Bilid-in

Compass

QMC5883

Baud Rate

115200bps

Protocol

Dual NMEA/UBLOX

Output Frequency

1Hz-10Hz,10Hz default

Speed Accuracy

0.05m/s

Horizontal Positioning Accuracy

2D ACC1.5m(outdoor)

Receiver Sensitivity

Trace -166dBm; Capture -160dBm

Dynamic Characteristics

Height 50000m; Speed 500m/s; Acceleration 4G

Operating Temperature

-40C-+85C

Storage temperature

-40C-+105C

Weight

7.5g

Size

18*18*8mm

Additional information
ColorM10Q 250 GPS, M10Q 120 GPS, M10Q 180 GPS
